| Brand Name: | WSD |
| Model Number: | FTD-2458PB1313VH30B |
| MOQ: | 2 |
| Price: | $50~300 |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 500 |
| 2400 to 2500 | 5150 to 5850 | |
|---|---|---|
| Freq.Range-MHz | 100 | 700 |
| Polarization | Vertical and Horizontal | |
| Gain-dBi | 13 | 13 |
| Beam Electrical Downtilt-° | 0 | |
| Half-power beam width-° | H:30 E:30 | H:30 E:30 |
| Cross-pol-isolation-dB | ≥ 20 | ≥ 25 |
| F/B-dB | ≥ 20 | ≥ 25 |
| Impedance-Ω | 50 | |
| VSWR | ≤ 1.5 | ≤ 2.0 |
| Max.Power-W | 50 | |
| Lightning Protection | DC Grounded | |
| Connector | 2 ×N female |
|---|---|
| Connector Position | Back |
| Dimension-MM | About 260×190×30 |
| Weight-KG | About 1.2 |
| Radome material | ABS |
| Radome color | White |
| Mechanical tilt-° | 0 to 30 |
| Operational Temperature-℃ | -40 to 60 |
| Storage Temperature-℃ | -55 to 85 |
| Relative Humidity-% | 5 to 95 |
| Rated Wind Velocity-M/S | 60 |
| Mounting way | Mast【Φ35 to 50】 |
