| Brand Name: | WSD |
| Model Number: | FTQ-2470MQX1212V6AN |
| MOQ: | 1 |
| Price: | $50~300 |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 500 |
| Freq.Range-MHz | 2400 to 2484 | 5150 to 7125 |
|---|---|---|
| Bandwidth-MHz | 84 | 1975 |
| Polarization | Vertical | Vertical |
| Gain-dBi | 12 | 12 |
| Half-power beam width-° | H:360 E:15 | H:360 E:10 |
| Preset electrical downtilt-° | 5 | 5 |
| Impedance-Ω | 50 | |
| VSWR | ≤ 1.5 | ≤ 2.5 |
| Max.Power-W | 20 | |
| Connector | 6×N Female |
| Connector Position | Bottom |
| Dimension-MM | About Φ146×500 |
| Weight-KG | About 2.3 |
| Radome material | ABS or PC |
| Radome color | White |
| Operational Temperature-℃ | -40 to 60 |
| Storage Temperature-℃ | -55 to 85 |
| Relative Humidity-% | 5 to 95 |
| Rated Wind Velocity-M/S | 60 |
| Mounting way | Mast |
| Mast Diameter-MM | Φ75 to 140 |
