| Brand Name: | winspread |
| Model Number: | FTQ-2458MXD0304V6A |
| MOQ: | 1 |
| Price: | $50~300 |
| Payment Terms: | D/A |
| Supply Ability: | 500 |
| Parameter | 2400 to 2500 MHz | 5150 to 5850 MHz |
|---|---|---|
| Frequency Range (MHz) | 2400 to 2500 | 5150 to 5850 |
| Bandwidth (MHz) | 100 | 700 |
| Polarization | Vertical | |
| Gain (dBi) | 2.5 | 4 |
| Impedance (Ω) | 50 | |
| VSWR | ≤ 1.5 | ≤ 2.0 |
| Max. Power (W) | 20 | |
| Parameter | Specification |
|---|---|
| Connector | 6*RPTNC male or Customized |
| Connector Quantity | Six 2.4/5GHz Connector |
| Connector Position | Cable outgoing |
| Cable Length (CM) | 20CM or Customized |
| Dimension (MM) | About Φ145*42 |
| Weight (G) | About 180 |
| Radome material | ABS |
| Radome color | White |
| Operational Temperature (℃) | -40 to 60 |
| Storage Temperature (℃) | -55 to 85 |
| Relative Humidity (%) | 5 to 95 |
| Mounting way | Nuts fixed to the ceiling |
