| Brand Name: | WSD |
| Model Number: | CA-620 |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 100 |
| No. | Component | Specification | Qty | Remark |
| 1 | Main Controller |
Frequency range: GSM900/1800MHz, WCDMA2100MHz, LTE multi bands customizable Bandwidth: 5MHz Synchronization: GPS & network dual synchronization Sensitivity: below -102dBm Effective distance: 0~1000m Single channel power:20W, total 10 channels Size:48447488mm Weight:16kg |
2 PCS | |
| 2 | Signal Detector |
Compatible with GSM/WCDMA/LTE adjustable frequency band Rated power:2.5W Dimension:18610621mm Gross weight with accessories:0.5kg |
1 PCS | |
| 3 | Shark Fin Aerial |
Frequency:700-2700MHz Gain:1.0-4.0dBi VSWR: no more than 2.0 Outline size:200120110mm Net weight:0.3kg |
3 PCS | |
| 4 | Direction Finding Antenna |
Four-way direction detection Fit for vehicle top cabinet installation |
1 PCS | Optional part |
| 5 | Power Battery Module |
Lithium iron phosphate battery Capacity:52Ah DC input:10.4-16V, 320W AC output:220V±10%,50Hz,3000VA Size:500440134mm Weight:28kg |
1 SET | |
| 6 | Control Terminal | Windows based laptop or tablet PC | 1 PCS | Standard equipped |
| 7 | Spare Parts | Industrial router, network line, power cord, GPS antenna, power socket | 1 SET |
