| Brand Name: | winspread |
| Model Number: | FDD-80W-150100-DPSL |
| MOQ: | 1 |
| Price: | $650-1000 |
| Payment Terms: | L/C,D/A |
| Supply Ability: | 100 |
| No. | Parameter | UL | DL |
|---|---|---|---|
| 1 | Frequency Range | B1: 1920-1980MHz B3: 1710-1785MHz B7: 2500-2570MHz B8: 880-915MHz |
B1: 2110-2170MHz B3: 1805-1880MHz B7: 2620-2690MHz B8: 925-960MHz |
| 2 | Maximum Output Power | -- | 49±1dBm |
| 3 | Maximum Input Level | -- | +10dBm |
| 4 | Max. Gain | 25±2dB | 53±2dB |
| 5 | ALC Range | -- | ≥10dB |
| 6 | Gain Adjustment Range | -- | ≥25dB |
| 7 | Gain Flatness | ATT 10dB: ≤±1dB ATT 20dB: ≤±1dB ATT 25dB: ≤±1.5dB |
|
| 8 | VSWR | ≤1.4:1 (Uplink port) | ≤1.4:1 (Downlink port) |
| 9 | In-band Ripple | ≤2.5dB | |
| 10 | Noise Figure | ≤2dB | -- |
| 12 | EVM | ≤8% (PAR 10.0dB) | |
| 13 | Operating Voltage | 28V DC, dual-wire power supply configuration | |
| 14 | Operating Current | With APD: ≤9A | |
| 15 | Working Temperature | -40～+55℃ | |
| 16 | Over-Temperature Protection | +85°C: Alarm and shutdown +65°C: Restart |
|
| 17 | Baud Rate | 9600 | |
